NO.

Name

Quant.

Remark

1

 Double head motorized decoiler

1

Max 3T(1.5T for each head)

2

Leveling machine

1

5.5kw frequency change driving-motor,speed adjustable

3

Support frame(loop sensor)

2

Roller type

4

NC300 servo motor Feeder

1

1.5kw Yaskawa Servo motor drive

5

Punching press

1

125tons Capacity made in   china

6

Punching mould( one for rack profiles,one for L profiles)

2sets

       Cr12

7

Main forming
Machine unit

1set

 Cast iron stands
14 forming stations
15kw motor
Gearbox drive
Fast-change machine frame
Hydraulic flying shear

8

Hydraulic flying shear

1 set

Hydraulic flying shear for rack profile and L profile,pre-cut for Z profiles

9

Cutting blade

4sets

Material Cr12.HCR58-62

10

Run-out table

2pcs

Steel frame with Rollers

11

Electric panel

2sets( 1set for mail machine,1 set for servo-feeder system)

PLC control system,Panasonic or Omron,Omron encoder,Yaskawa inverter
